HCET RoHS KSD301 Bimetal Thermal Switch Thermostat Adjustable 120C Cut-off Switch for Water Heaters

As a classic solution in the field of bimetallic temperature control, HCET KSD301 series thermostat adopts precision bimetallic disc technology,

which allows customizable ±3℃ high-precision temperature control in the range of - 20℃ to 280℃. The product is triple certified by UL, CE,

and RoHS, supports a load capacity of up to 16A/250V, and its snap-action disconnect mechanism effectively prevents arcing,

making it especially suitable for coffee makers, water dispensers, charging piles, and other devices that require frequent temperature cycling.

Product feature:

• Multi-scenario adaptable design
  By adjusting the curvature of bimetallic disc and contact material, the temperature set point (-20 - 250℃) can be customized to meet the needs of different scenarios, such as overheating protection for coffee machines and temperature monitoring for electric vehicle charging piles.
• Enhanced Electrical Performance
  Silver nickel alloy contacts with ceramic base maintain >100,000 cycles of mechanical life under 16A/250V operating conditions, with a contact resistance of ≤50mΩ.
• Enhanced environmental resistance
  Adopting flame-retardant shell and imported spring sheet, passing 85℃/85%RH 1000 hours salt spray test, suitable for kitchen appliances, outdoor lighting equipment and other harsh environments.

Electrical Characteristics:

Product detail

Application

Nanjing Haichuan Electronic Co., Ltd., located in Nanjing Luhe Economic Development Zone, is a national high-tech enterprise specializing in the production of high-end motor protectors, overcurrent protectors, thermostats, thermal protectors, temperature switches, temperature control switches, and temperature sensors. The company has passed the IATF16949 quality management system certification and has multiple independent patents. Its products have passed UL, TUV, CQC, and PSE international safety certification, The company adopts advanced automation equipment production technology, and its various series of products are widely used in fields such as glass lifter motors, wiper motors, seat motors, mixers, tubular motors, electric tools, battery packs, heating pads, new energy, etc. Haichuan embraces all rivers and pursues excellence. With professional technology, Haichuan is committed to providing reliable comprehensive solutions for overheating and overcurrent protection.
